端到端测试(End-to-End Testing / E2E Testing)

端到端测试(End-to-End Testing / E2E Testing)

一句话总结:从用户视角测试完整业务流程,确保系统各部分协同工作正常。

🌟 快速理解(小白入门)

用生活化类比

就像试驾汽车

  • 单元测试 = 检查发动机、刹车、轮胎(单个零件)
  • 集成测试 = 检查发动机和变速箱能否配合(两个零件)
  • 端到端测试 = 真实试驾,从启动、加速、转弯到停车(完整流程)

就像点外卖

1
用户打开 App → 浏览商家 → 选择商品 → 加入购物车 → 下单 → 支付 → 等待配送 → 收到外卖

端到端测试会模拟这整个流程,确保每一步都正常工作。


真实场景

电商购物流程

1
2
3
4
5
6
7
8
9
10
11
1. 用户登录
2. 搜索商品 "iPhone 15"
3. 点击商品详情
4. 选择颜色、容量
5. 加入购物车
6. 进入购物车
7. 点击结算
8. 填写收货地址
9. 选择支付方式
10. 完成支付
11. 查看订单状态

端到端测试会自动执行这 11 个步骤,验证每一步是否正常。


📌 核心概念

定义

端到端测试(E2E Testing):从用户的角度测试完整的业务流程,验证系统的所有组件(前端、后端、数据库、第三方服务)能否协同工作。

通俗解释

  • 单元测试:测试一个函数
  • 集成测试:测试两个模块的接口
  • 端到端测试:测试整个系统,从用户点击按钮到数据库更新

关键特征

特征 说明 示例
用户视角 从用户的角度测试 模拟用户点击、输入、滚动
完整流程 测试完整的业务流程 从登录到下单到支付
真实环境 在接近生产的环境中测试 使用真实的数据库、API
跨系统 涉及多个系统和服务 前端 + 后端 + 数据库 + 第三方
自动化 通常使用自动化工具 Selenium、Playwright、Cypress

🎯 为什么需要端到端测试?

真实案例

案例 1:亚马逊购物车 bug

问题:用户加入购物车的商品,在支付时消失了。

原因

  • 前端:商品加入购物车成功 ✅
  • 后端:购物车 API 正常 ✅
  • 数据库:购物车数据保存成功 ✅
  • 问题:支付时,前端调用的是旧的购物车 API,导致数据不同步 ❌

损失:用户流失、订单减少、品牌信誉受损

教训:单元测试和集成测试都通过了,但端到端测试能发现这个问题。


案例 2:银行转账失败

问题:用户转账成功,但收款方没有收到钱。

原因

  • 转账服务:扣款成功 ✅
  • 通知服务:发送成功通知 ✅
  • 问题:扣款和入账之间的事务没有正确处理,导致钱”消失”了 ❌

损失:客户投诉、监管处罚、系统紧急修复

教训:端到端测试能发现跨服务的事务问题。


行业数据

研究机构 数据 说明
Gartner 80% 的生产 bug 来自集成问题 单元测试无法发现
Google E2E 测试覆盖率 ≥10% 测试金字塔的顶端
Microsoft E2E 测试发现的 bug 修复成本是单元测试的 100 倍 越晚发现,成本越高

✅ 端到端测试的优势

优势 1:发现集成问题 🔌

通俗解释

就像组装电脑,每个零件单独测试都正常,但组装后可能不兼容。

专业说明

端到端测试能发现:

  • 前后端接口不匹配
  • 数据库事务问题
  • 第三方服务集成失败
  • 跨服务的数据流问题

代码示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
# 端到端测试:完整的购物流程
def test_complete_shopping_flow():
# 步骤 1:用户登录
driver.get("https://example.com/login")
driver.find_element(By.ID, "username").send_keys("test@example.com")
driver.find_element(By.ID, "password").send_keys("password123")
driver.find_element(By.ID, "login-btn").click()

# 验证登录成功
assert "欢迎" in driver.page_source

# 步骤 2:搜索商品
driver.find_element(By.ID, "search-box").send_keys("iPhone 15")
driver.find_element(By.ID, "search-btn").click()

# 验证搜索结果
assert "iPhone 15" in driver.page_source

# 步骤 3:加入购物车
driver.find_element(By.CLASS_NAME, "add-to-cart").click()

# 验证购物车数量
cart_count = driver.find_element(By.ID, "cart-count").text
assert cart_count == "1"

# 步骤 4:结算
driver.find_element(By.ID, "checkout-btn").click()

# 步骤 5:填写地址
driver.find_element(By.ID, "address").send_keys("北京市朝阳区xxx")
driver.find_element(By.ID, "phone").send_keys("13800138000")

# 步骤 6:选择支付方式
driver.find_element(By.ID, "payment-wechat").click()

# 步骤 7:提交订单
driver.find_element(By.ID, "submit-order").click()

# 验证订单创建成功
assert "订单提交成功" in driver.page_source

# 步骤 8:验证数据库
order = db.query("SELECT * FROM orders WHERE user_id = 123 ORDER BY created_at DESC LIMIT 1")
assert order.status == "pending_payment"
assert order.total > 0

行业最佳实践

  • Google:E2E 测试覆盖核心业务流程(登录、支付、下单)
  • Netflix:E2E 测试覆盖视频播放的完整流程
  • Uber:E2E 测试覆盖叫车、支付、评价的完整流程

优势 2:验证用户体验 👤

通俗解释

就像试驾汽车,不仅要检查零件,还要确保驾驶体验流畅。

专业说明

端到端测试能验证:

  • 页面加载速度
  • 按钮是否可点击
  • 表单验证是否正确
  • 错误提示是否友好

代码示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
# 测试用户体验
def test_user_experience():
# 测试页面加载速度
start_time = time.time()
driver.get("https://example.com")
load_time = time.time() - start_time

# 验证加载时间 < 3 秒
assert load_time < 3, f"页面加载时间过长:{load_time}秒"

# 测试按钮可点击
add_to_cart_btn = driver.find_element(By.ID, "add-to-cart")
assert add_to_cart_btn.is_displayed()
assert add_to_cart_btn.is_enabled()

# 测试表单验证
driver.find_element(By.ID, "email").send_keys("invalid-email")
driver.find_element(By.ID, "submit").click()

# 验证错误提示
error_msg = driver.find_element(By.CLASS_NAME, "error-message").text
assert "请输入有效的邮箱地址" in error_msg

优势 3:提高信心 💪

通俗解释

就像飞机起飞前的全面检查,确保所有系统正常,才敢起飞。

专业说明

端到端测试通过后,团队对发布有信心:

  • 核心业务流程正常
  • 用户体验流畅
  • 数据一致性保证
  • 第三方服务集成正常

修复成本对比

阶段 修复成本 说明
开发阶段 $1 单元测试发现
测试阶段 $10 集成测试发现
发布前 $100 E2E 测试发现
生产环境 $1000+ 用户发现,紧急修复

⚠️ 端到端测试的挑战

挑战 1:执行缓慢 ⏱️

问题

  • 单元测试:毫秒级
  • 集成测试:秒级
  • 端到端测试:分钟级

原因

  • 需要启动浏览器
  • 需要加载完整页面
  • 需要等待网络请求
  • 需要等待动画、渲染

解决方案

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
# 1. 并行执行测试
pytest -n 4 # 使用 4 个进程并行执行

# 2. 只测试关键流程
@pytest.mark.critical
def test_critical_flow():
# 只测试核心业务流程
pass

# 3. 使用无头浏览器
options = webdriver.ChromeOptions()
options.add_argument('--headless') # 无头模式,更快
driver = webdriver.Chrome(options=options)

# 4. 复用浏览器会话
@pytest.fixture(scope="session")
def driver():
driver = webdriver.Chrome()
yield driver
driver.quit()

挑战 4:维护成本高 💰

问题

  • UI 变化导致测试失败
  • 选择器失效(By.ID, By.CLASS_NAME
  • 测试数据过期

解决方案

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
# 1. 使用 Page Object Model(POM)
class LoginPage:
def __init__(self, driver):
self.driver = driver
self.username_input = (By.ID, "username")
self.password_input = (By.ID, "password")
self.login_btn = (By.ID, "login-btn")

def login(self, username, password):
self.driver.find_element(*self.username_input).send_keys(username)
self.driver.find_element(*self.password_input).send_keys(password)
self.driver.find_element(*self.login_btn).click()

# 使用
login_page = LoginPage(driver)
login_page.login("test@example.com", "password123")

# 2. 使用数据驱动测试
@pytest.mark.parametrize("username,password", [
("test1@example.com", "password1"),
("test2@example.com", "password2"),
("test3@example.com", "password3"),
])
def test_login(username, password):
login_page.login(username, password)
assert "欢迎" in driver.page_source

# 3. 使用测试数据工厂
class UserFactory:
@staticmethod
def create_test_user():
return {
"username": f"test_{uuid.uuid4()}@example.com",
"password": "password123",
"name": "测试用户"
}

user = UserFactory.create_test_user()

🔄 端到端测试的类型

1. 水平 E2E 测试

定义:测试单个应用的完整流程

示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
# 测试电商 Web 应用
def test_horizontal_e2e():
# 1. 登录
login_page.login("test@example.com", "password123")

# 2. 搜索商品
search_page.search("iPhone 15")

# 3. 加入购物车
product_page.add_to_cart()

# 4. 结算
cart_page.checkout()

# 5. 支付
payment_page.pay_with_wechat()

# 6. 验证订单
assert order_page.get_order_status() == "pending_payment"

2. 垂直 E2E 测试

定义:测试跨多个系统的流程

示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
# 测试电商系统(Web + 移动 App + 后台管理)
def test_vertical_e2e():
# 1. 用户在 Web 下单
web_driver.get("https://example.com")
web_driver.find_element(By.ID, "add-to-cart").click()
web_driver.find_element(By.ID, "checkout").click()

# 2. 管理员在后台处理订单
admin_driver.get("https://admin.example.com")
admin_driver.find_element(By.ID, "orders").click()
admin_driver.find_element(By.ID, "approve").click()

# 3. 用户在移动 App 查看订单状态
mobile_driver.find_element(By.ID, "my-orders").click()
status = mobile_driver.find_element(By.ID, "order-status").text
assert status == "已发货"

📋 如何执行端到端测试

执行步骤

1
2
3
4
5
6
7
8
9
graph TD
A[1. 识别用户场景] --> B[2. 设计测试用例]
B --> C[3. 准备测试环境]
C --> D[4. 编写测试脚本]
D --> E[5. 执行测试]
E --> F{是否通过?}
F -->|否| G[6. 调试修复]
G --> E
F -->|是| H[7. 生成报告]

1. 识别用户场景 🎯

核心业务流程

场景 优先级 说明
用户注册 P0 新用户必经流程
用户登录 P0 所有功能的前提
商品搜索 P0 核心功能
加入购物车 P0 购物流程
下单支付 P0 收入来源
查看订单 P1 用户关心
退款退货 P1 售后服务
评价商品 P2 辅助功能

2. 设计测试用例 ✍️

测试用例模板

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
def test_user_registration_flow():
"""
测试用例 ID: E2E-001
测试目标: 验证用户注册流程
前置条件: 无
测试步骤:
1. 打开注册页面
2. 填写用户名、邮箱、密码
3. 点击注册按钮
4. 验证邮箱
5. 登录
预期结果: 用户注册成功并自动登录
"""
# 步骤 1
driver.get("https://example.com/register")

# 步骤 2
driver.find_element(By.ID, "username").send_keys("testuser")
driver.find_element(By.ID, "email").send_keys("test@example.com")
driver.find_element(By.ID, "password").send_keys("password123")

# 步骤 3
driver.find_element(By.ID, "register-btn").click()

# 步骤 4
# 模拟邮箱验证
verification_code = get_verification_code_from_email("test@example.com")
driver.find_element(By.ID, "code").send_keys(verification_code)
driver.find_element(By.ID, "verify-btn").click()

# 步骤 5
assert "欢迎" in driver.page_source
assert driver.current_url == "https://example.com/home"

3. 准备测试环境 🔧

环境要求

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
# docker-compose.yml
version: '3'
services:
frontend:
build: ./frontend
ports:
- "3000:3000"
environment:
- API_URL=http://backend:8000

backend:
build: ./backend
ports:
- "8000:8000"
environment:
- DATABASE_URL=postgresql://test_user:test_pass@database:5432/test_db
- REDIS_URL=redis://redis:6379
depends_on:
- database
- redis

database:
image: postgres:14
environment:
POSTGRES_DB: test_db
POSTGRES_USER: test_user
POSTGRES_PASSWORD: test_pass

redis:
image: redis:7

selenium:
image: selenium/standalone-chrome
ports:
- "4444:4444"

4. 编写测试脚本 💻

完整示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
import pytest
from selenium import webdriver
from selenium.webdriver.common.by import By
from selenium.webdriver.support.ui import WebDriverWait
from selenium.webdriver.support import expected_conditions as EC

class TestE2E:
@pytest.fixture(scope="class")
def driver(self):
options = webdriver.ChromeOptions()
options.add_argument('--headless')
driver = webdriver.Chrome(options=options)
driver.implicitly_wait(10)
yield driver
driver.quit()

def test_complete_shopping_flow(self, driver):
# 1. 登录
driver.get("https://example.com/login")
driver.find_element(By.ID, "username").send_keys("test@example.com")
driver.find_element(By.ID, "password").send_keys("password123")
driver.find_element(By.ID, "login-btn").click()

# 等待登录成功
WebDriverWait(driver, 10).until(
EC.presence_of_element_located((By.ID, "user-menu"))
)

# 2. 搜索商品
driver.find_element(By.ID, "search-box").send_keys("iPhone 15")
driver.find_element(By.ID, "search-btn").click()

# 等待搜索结果
WebDriverWait(driver, 10).until(
EC.presence_of_element_located((By.CLASS_NAME, "product-item"))
)

# 3. 点击第一个商品
driver.find_element(By.CLASS_NAME, "product-item").click()

# 4. 加入购物车
driver.find_element(By.ID, "add-to-cart").click()

# 等待加入成功
WebDriverWait(driver, 10).until(
EC.text_to_be_present_in_element((By.ID, "cart-count"), "1")
)

# 5. 进入购物车
driver.find_element(By.ID, "cart-icon").click()

# 6. 结算
driver.find_element(By.ID, "checkout-btn").click()

# 7. 填写地址
driver.find_element(By.ID, "address").send_keys("北京市朝阳区xxx")
driver.find_element(By.ID, "phone").send_keys("13800138000")

# 8. 选择支付方式
driver.find_element(By.ID, "payment-wechat").click()

# 9. 提交订单
driver.find_element(By.ID, "submit-order").click()

# 10. 验证订单创建成功
WebDriverWait(driver, 10).until(
EC.presence_of_element_located((By.CLASS_NAME, "success-message"))
)

success_msg = driver.find_element(By.CLASS_NAME, "success-message").text
assert "订单提交成功" in success_msg

🛠️ 端到端测试工具推荐

前端 E2E 测试工具

工具 语言 特点 学习曲线 推荐度
Playwright JS/Python/Java 快速、稳定、跨浏览器 ⭐⭐⭐⭐⭐
Cypress JavaScript 易用、调试友好 ⭐⭐⭐⭐⭐
Selenium 多语言 成熟、社区大 ⭐⭐⭐⭐
Puppeteer JavaScript Chrome 专用、快速 ⭐⭐⭐⭐

Playwright 示例(推荐)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
from playwright.sync_api import sync_playwright

def test_shopping_flow():
with sync_playwright() as p:
# 启动浏览器
browser = p.chromium.launch(headless=True)
page = browser.new_page()

# 1. 登录
page.goto("https://example.com/login")
page.fill("#username", "test@example.com")
page.fill("#password", "password123")
page.click("#login-btn")

# 2. 搜索商品
page.fill("#search-box", "iPhone 15")
page.click("#search-btn")

# 3. 加入购物车
page.click(".product-item:first-child")
page.click("#add-to-cart")

# 4. 验证购物车数量
cart_count = page.text_content("#cart-count")
assert cart_count == "1"

browser.close()

Cypress 示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
describe('Shopping Flow', () => {
it('should complete shopping flow', () => {
// 1. 登录
cy.visit('https://example.com/login')
cy.get('#username').type('test@example.com')
cy.get('#password').type('password123')
cy.get('#login-btn').click()

// 2. 搜索商品
cy.get('#search-box').type('iPhone 15')
cy.get('#search-btn').click()

// 3. 加入购物车
cy.get('.product-item').first().click()
cy.get('#add-to-cart').click()

// 4. 验证购物车数量
cy.get('#cart-count').should('have.text', '1')
})
})

📊 最佳实践

1. 遵循测试金字塔 🔺

1
2
3
4
5
6
7
      /\
/E2E\ 10% - 端到端测试(慢、贵、脆弱)
/------\
/集成测试\ 20% - 集成测试(中等)
/----------\
/ 单元测试 \ 70% - 单元测试(快、便宜、稳定)
/--------------\

原则

  • 70% 单元测试:测试单个函数、类
  • 20% 集成测试:测试模块间的接口
  • 10% 端到端测试:测试核心业务流程

2. 只测试关键流程 🔑

不要测试所有功能,只测试核心业务流程

功能 是否需要 E2E 测试 原因
用户注册 ✅ 需要 核心流程
用户登录 ✅ 需要 核心流程
下单支付 ✅ 需要 核心流程
修改个人资料 ❌ 不需要 使用集成测试即可
查看帮助文档 ❌ 不需要 使用单元测试即可

3. 使用 Page Object Model 📄

优势

  • 提高代码复用性
  • 降低维护成本
  • 提高可读性

示例

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
# pages/login_page.py
class LoginPage:
def __init__(self, page):
self.page = page
self.username_input = "#username"
self.password_input = "#password"
self.login_btn = "#login-btn"

def login(self, username, password):
self.page.fill(self.username_input, username)
self.page.fill(self.password_input, password)
self.page.click(self.login_btn)

# tests/test_login.py
def test_login():
login_page = LoginPage(page)
login_page.login("test@example.com", "password123")
assert "欢迎" in page.content()

4. 并行执行测试 ⚡

1
2
3
4
5
# Pytest 并行执行
pytest -n 4 tests/e2e/

# Playwright 并行执行
pytest --numprocesses 4 tests/e2e/

5. 使用 CI/CD 集成 🔄

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
# .github/workflows/e2e.yml
name: E2E Tests

on: [push, pull_request]

jobs:
e2e:
runs-on: ubuntu-latest

steps:
- uses: actions/checkout@v2

- name: Set up Python
uses: actions/setup-python@v2
with:
python-version: 3.9

- name: Install dependencies
run: |
pip install -r requirements.txt
playwright install

- name: Start services
run: docker-compose up -d

- name: Run E2E tests
run: pytest tests/e2e/

- name: Upload screenshots
if: failure()
uses: actions/upload-artifact@v2
with:
name: screenshots
path: screenshots/

📊 总结对比

E2E vs 集成测试 vs 单元测试

维度 单元测试 集成测试 端到端测试
测试范围 单个函数/类 多个模块 完整系统
测试速度 快(毫秒) 中(秒) 慢(分钟)
测试成本
问题定位 容易 中等 困难
测试数量 多(70%) 中(20%) 少(10%)
依赖 部分 全部
维护成本

🎓 学习资源

书籍推荐

  • 《测试驱动开发》- Kent Beck
  • 《持续交付》- Jez Humble
  • 《Google 软件测试之道》- James A. Whittaker

在线课程

官方文档


🔗 相关主题

  • [[单元测试]] - E2E 测试的基础
  • [[集成测试]] - E2E 测试的前置步骤
  • [[性能测试]] - E2E 测试的补充
  • [[自动化测试]] - E2E 测试的实现方式

💡 快速参考卡片

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
端到端测试速查表
================

定义:从用户视角测试完整业务流程

核心价值:
✅ 发现集成问题
✅ 验证用户体验
✅ 提高发布信心

测试类型:
- 水平 E2E(单个应用)
- 垂直 E2E(跨多个系统)

推荐工具:
- Playwright(推荐)
- Cypress
- Selenium

最佳实践:
1. 遵循测试金字塔(10% E2E)
2. 只测试关键流程
3. 使用 Page Object Model
4. 并行执行测试
5. CI/CD 集成

测试金字塔:
70% 单元测试
20% 集成测试
10% 端到端测试 ← 你在这里

常见挑战:
- 执行缓慢 → 并行执行
- 环境复杂 → Docker Compose
- 调试困难 → 详细日志 + 截图
- 维护成本高 → Page Object Model

挑战 2:环境复杂 🔧

问题

端到端测试需要:

  • 前端服务器
  • 后端服务器
  • 数据库
  • Redis
  • 第三方服务(支付、短信)

解决方案

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
# docker-compose.yml
version: '3'
services:
frontend:
build: ./frontend
ports:
- "3000:3000"

backend:
build: ./backend
ports:
- "8000:8000"
depends_on:
- database
- redis

database:
image: postgres:14
environment:
POSTGRES_DB: test_db

redis:
image: redis:7

mock_payment:
image: mockserver/mockserver
ports:
- "1080:1080"
1
2
3
4
5
6
7
8
# 一键启动所有服务
docker-compose up -d

# 运行 E2E 测试
pytest tests/e2e/

# 一键停止所有服务
docker-compose down

挑战 3:调试困难 🐛

问题

测试失败时,不知道是哪个环节出了问题:

  • 前端?
  • 后端?
  • 数据库?
  • 第三方服务?

解决方案

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
# 1. 详细的日志
import logging

def test_shopping_flow():
logging.info("步骤 1:用户登录")
driver.get("https://example.com/login")
driver.find_element(By.ID, "username").send_keys("test@example.com")
driver.find_element(By.ID, "password").send_keys("password123")
driver.find_element(By.ID, "login-btn").click()
logging.info("登录成功")

logging.info("步骤 2:搜索商品")
driver.find_element(By.ID, "search-box").send_keys("iPhone 15")
driver.find_element(By.ID, "search-btn").click()
logging.info("搜索成功")

# ...

# 2. 截图
def test_shopping_flow():
try:
# 测试步骤
pass
except Exception as e:
# 失败时截图
driver.save_screenshot(f"error_{time.time()}.png")
raise

# 3. 录屏
from selenium.webdriver.common.desired_capabilities import DesiredCapabilities

caps = DesiredCapabilities.CHROME.copy()
caps['goog:loggingPrefs'] = {'browser': 'ALL'}
driver = webdriver.Chrome(desired_capabilities=caps)

# 4. 网络请求日志
logs = driver.get_log('performance')
for log in logs:
print(log)
